MBS-YP18 Steel Swing Hospital Door
Galvanized-steel hospital swing door with internal reinforcement, sealed frame, electrostatic powder-coated finish and adhesive-pressed panel construction for ward and corridor use.
Specifications
- Model
- MBS-YP18
- Max single-leaf opening
- 1300 x 2400 mm
- Max double-leaf opening
- 2400 x 2400 mm
- Door-frame side-wall height
- 100-500 mm
- Vision panel options
- 180 x 700 mm or 180 x 1700 mm
- Surface
- Electrostatic powder coating
- Fire seal strip
- Optional
Galvanized-steel hospital doors with internal reinforcement for dimensional stability and impact resistance.
A sealed frame structure supports sound insulation and shock absorption, while adhesive pressing technology eliminates exposed screws around the door panel.
Key features
Electrostatic powder-coated surface with a smooth, uniform finish.
Waterproof, impact-resistant, antibacterial, sound-insulating and antistatic construction as described in the source catalog.
Optional fire seal strip.
Applications
Patient rooms, corridors and utility areas.
Configuration options
The hospital door range is supplied with a choice of edging: aluminum profile or stainless steel, selected per project.
Observation windows are available as black-edged flat glass in a range of sizes, including round and rectangular formats depending on the model.
Door locks, closers, floor springs and access-control interfaces are available as project hardware.
Activation and control options include infrared sensors, foot sensors, keypads and remote controls.
